EPX HMI PowerStation Family
Big HMI capabilities in a compact, affordable package
This CTC-designed and manufactured PowerStation is an
Industrial PC with an 8?or 10?TFT display and analog resistive touchscreen.
Pre-installed and licensed with award-winning InteractX Windows HMI
unlimited-tag runtime software, EPX PowerStations combine the power of the
standard Windows XP Pro operating systems with a hardened x86 hardware
platform for embedded computing needs.
Each EPX system includes a range of options such as CompactFlash storage,
USB ports, RS-232 and RS-232/422/485 ports, and a 100BaseT Ethernet port.
CTC PowerStations allow you to choose the right system for your application
without sacrificing the features you need!
|
 |
- InteractX Window HMI with Unlimited Tags and 60+ Communication
Drivers
- CPU: Embedded 650MHz Pentium III
- DRAM: 512MB
- OS: Windows XP
- Storage: 40 GB or CompactFlash (80 GB HD option)
- 64 MB Video Memory (shared)
- NEMA4/4x
- UL/CUL/CE
- 24-month warranty
- Display-Based Panel Mount, Color TFT, Analog Resistive
Touchscreen Systems
- 8" VGA (640x480)
- 10" SVGA (800x600)
|
Award Winning
Unlimited TAG HMI RUNTIME
installed and licensed
on every system!
|
| Systems Include : |
| Windows HMI |
- InteractX Runtime Installed and Licensed*
- Unlimited Tags, Unlimited Panels, Unlimited Alarms,...
- 60+ Ethernet, Serial and Industrial network communications drivers
- Tag OPC Server, OPC Client and Networking
- Integrated ActiveX, Visual Basic and Mulitlanguage
|
| High Performance Features |
- 650MHz Ultra Low Voltage Intel Celeron
- 512MB Shared PC100 SODIMM
- 64MB Shared System Memory
- Hard Drive - 3.5?40GB, 7200 RPM UltraATA/100 (80GB optional)**
- Microsoft® Windows® 2000 or XP Pro
|
| Reliability |
- Option for Windows OS on Compact Flash
- Tested to extremes
- HALT / HASS Certified
- Shock/Vibration/Temperature
- Electrical Emissions and Immunity
- Chemical Resistance
- UL rated NEMA Type 4/4x
- UL/CUL/CE?/li>
- 24 month warranty
|
| Display and Mounting Options |
| Display Based Systems |
- Includes flat panel display and Analog Resistive Touchscreen
- 8.0" VGA (640x480)
Color TFT
- 10.4" SVGA (800x600) Color TFT
|
* InteractX 2.1 or later required
** Actual storage volumes may be higher
?Class 1 Div 2 option not available |
